MX341 Automatic Voltage Regulator Dealer in Faridabad
| Frequency | 50-60Hz |
| Model Name/Number | MX341 |
| Brand | Stampford |
| Sensing Input Voltage | 190-264v Ac Max |
| Power Input Voltage | 140-220v Ac Max |
| Current | 3A |
| Output Voltage Max | 120VDC |
| Current Continuous | 2.7A |
| Intermittent | 6a for 10 Sec |
| Resistance | 150 OHM |
| Regulation | +/- 1% (See Note 1) |
| Thermal Drift | 0.03% Per OC Change in Avr Ambient (Note 2) |
| Soft Start Ramp Time | 3 Second |
| Avr Response | 10 ms |
| Filed Current to 90% | 80 ms |
| Machine Volts to 97% | 300 ms |
| External Voltage Adjustment | +/-10% With 1 K Ohm 1 Watt Trimmer (See Note 3) |
| Under Frequency Protection | Set Point 95% Hz (See Note 4) and Slope 170% Down to 30 Hz |
| Unit Power Dissipation | 12 Watts Maximum |
| Input Resistance | 1k Ohm |
| Sensitivity | 1v for 5% Generator Volts (Adjustable) |
| Maximum Input | +/- 5v Dc (See Note 5) |
| Quadrature Droop Input | 10 Ohms Burden |
| Max. Sensitivity | 0.07 a for 5% Droop 0pf |
| Max. Input | 0.33A |
| Over Excitation Protection | Set Point 75 V Dc |
| Time Delay | 10 Sec |
| Vibration | 20-100 Hz 50mm/sec and 100hz – 2khz 3.3g |
| Operating Temperature | -40 to +70 Degree Celsius |
| Relative Humidity | 95% |
| Storage Temperature | -55 to +85 Degree Celsius |
